KCD1 Rectangular Rocker Switch – 2-Pin SPST (6A 250VAC / 10A 125VAC)
R12,95
15 in stock
Description
Compact KCD1 rectangular snap-in rocker switch rated at 6A 250V AC / 10A 125V AC. Designed for reliable power control with a crisp latching action. Perfect for small household appliances, DIY power strips, automotive accessories, custom electronic enclosures, and robotics projects.
Key Features
-
Snap-In Panel Mount: Built-in side retention clips allow for fast, tool-free installation into rectangular panel cutouts.
-
Standard Terminal Size: Equipped with standard 4.8mm quick-connect spade lug terminals (also suitable for direct soldering).
-
High Electrical Life: Rated for 10,000+ switching cycles at full rated load.
Technical Specifications & Dimensions
| Feature / Spec | Measurement / Detail |
| Model | KCD1 |
| Contact Configuration | SPST (Single Pole Single Throw — 2 Pin) |
| Current / Voltage Rating | 6A 250V AC / 10A 125V AC |
| Panel Cutout Size | 19.0 mm × 13.0 mm (or ~21.0 mm × 15.0 mm outer bezel) |
| Overall Dimensions | ~21.0 mm × 15.0 mm × 25.0 mm (L × W × H) |
| Terminal Type | 4.8 mm Male Quick-Connect Blade / Solder Lug |
